As a high-precision and efficient machine tool, the core technology of CNC lathes involves many fields, such as CNC systems, mechanical transmission, precision control, etc. This article will explore the core technology of CNC lathe centering machine.
CNC system
The numerical control system is one of the core technologies of the CNC lathe center moving machine. Numerical control system refers to the automated scheduling of machine tool movements through computer control, achieving digital control of machining processes. The core technologies in the field of CNC systems include the design of CNC systems, programming methods, and control algorithms.
The design and development of CNC systems are the core and key to the manufacturing of CNC lathes. The design of a CNC system needs to consider the structure and characteristics of the machine tool itself, as well as the specificity of the actual machining process, to determine suitable control methods and algorithms. Nowadays, PC based DOS systems or embedded systems (such as CNC system boards) are generally used for CNC programming work.
mechanical drive
Mechanical transmission is one of the key technologies of the CNC lathe walking machine, characterized by high precision and high speed. Mechanical transmission includes the design and selection of various components, such as screw, ball screw, etc. These components, as the main mechanical components in CNC systems, require high precision and reliable use. The screw is a basic component in mechanical transmission, and its composition can be seen as a rod-shaped object with a helical profile, used to transmit power and motion. A screw is generally composed of a nut and a screw, which converts the power of the machining machine through rotation and linear motion.
For a centrifuge, an important component of mechanical transmission is the spindle and its related mechanisms. The spindle is the axis responsible for rotating the fixture and tool on the CNC lathe's center of gravity machine. It is an important component for cutting workpieces with machining tools, and the control of its speed and direction of rotation is crucial.
Precision control
Precision control is also one of the core technologies of CNC lathes, including control of machining quality, machining accuracy, and other aspects. The goal of precision control is to improve machining quality, reduce machining costs, and improve machining efficiency.
Firstly, the axis control of the CNC lathe spindle is usually carried out in a closed loop control environment. The hardware and software design of the axis control board are crucial, as the stability and response speed of the board directly affect the machining efficiency of the lathe. Especially in modern industrial applications, the precision requirements for machining workpieces are becoming increasingly high, therefore, research on precision control technology is becoming more and more in-depth.
Secondly, for some parameters that need to be controlled, such as the temperature generated during the machining process, sensors can also be used for real-time monitoring and control. In this way, the heating and cooling during the processing can meet the requirements separately, making it convenient to achieve diversified processing.
