Hello, everyone, this is HANBS, I am Sonya, recently I have been to the Mid-Autumn Festival ah, a while no share ah, of course, will not give up. So let's start today's sharing! Today I would like to share how much cnc lathe size. in fact, people who know cnc lathe know that there are still quite a lot of kinds of cnc lathe, so it is natural that its size will be a little different. cnc lathe size is varied, usually depends on their purpose, the size of the workpiece to be processed and the production needs. Here are a few key aspects of CNC lathe sizes:
1. Machining range
Maximum turning diameter: this is the maximum diameter of the workpiece that can be machined on a cnc lathe and usually varies between 150mm (6 inches) and 1000mm (40 inches). Small desktop grade cnc lathe usually machine diameters between 150mm-300mm, while large industrial grade cnc lathe can machine diameters up to 1000mm or more.
Maximum turning length:
This is the maximum length of the workpiece that the lathe can machine, usually from 200mm (8 inches) to 3000mm (120 inches) or longer. A small cnc lathe is suitable for shorter workpieces, while a large cnc lathe can machine long shafted parts (small ones also machine slender shafted parts).
2. cnc lathe external dimensions
The physical external dimensions of a cnc lathe depend on the machining capacity of its type:
Small desktop level cnc lathe: suitable for small parts processing, the general size of about 500mm * 1000mm * 1000mm.
Medium-sized cnc lathe: for medium-sized parts processing, with dimensions of about 2000mm*1500mm*1500mm.
Large industrial cnc lathe: can process large, heavy workpiece, size can reach 4000mm*2000mm*2000mm or even larger.
3.Spindle size
Spindle through-hole diameter: this refers to the diameter of the through-hole in the center of the spindle, determines the diameter of the bar that can be processed through the spindle. The diameter of the spindle through-hole of a small cnc lathe is usually 20-60mm, while the diameter of the spindle through-hole of a large lathe can exceed 100mm.
4.Lathe size
Bed length: determines the maximum workpiece length that the lathe can support. The longer the bed, the greater the length of the workpiece that can be processed. The bed can be from 500mm to 5000mm or even longer.
5. Other Considerations
Number and type of turret: small cnc lathes are usually equipped with a single turret, while large and versatile cnc lathes may be equipped with a double turret, or even have multi-axis control such as Y-axis, C-axis, and so on. Composite cnc lathe are usually equipped with multiple control axes.
Installation space: many people are actually concerned about this, so they ask for more details when purchasing a cnc lathe. When installing a cnc lathe, you need to consider the operating space. It is usually required to have at least 1-2m space around the lathe for operation and maintenance.
That's all for today's sharing, I hope it can help the people who need it, we will see you next time.
