Automatic centering machines have made a qualitative leap in processing efficiency and accuracy compared to CNC lathes. Due to the use of dual axis tool arrangement, the processing cycle time is greatly reduced. By shortening the tool exchange time between the tool arrangement and the opposite tool table, multiple tool table overlap function, thread chip effective axis movement overlap function, and direct spindle indexing function during secondary processing, the idle travel time is shortened.
1. If the diameter of the automatic centrifuge drill bit is large, or if the trial drilling holes are too deviated, the collet can use a chisel to chisel several grooves on the side with more hole allowance.
2. The XYZ three axis ball screw of the machine tool adopts P3 grade double nut pre tensioned ball screw provided by Taiwan Shangyin. The bearings at both ends of the ball screw use P4 grade ball screw special paired centripetal thrust bearings imported from Japan, and all three axes are pre tensioned.
3. Adopting reliable and safe electrical components and professional circuit design to ensure the safe operation of the machine;
4. Install the multi spindle chuck of the walking machine on the drill chuck and calibrate it so that the radial runout of the cone surface is within 0.02mm. Then, use the cone surface to calibrate the V-shaped cone and fix the V-shaped iron.
