The CNC centring machine is overall beautiful and generous, with novel and outstanding shape, constantly improved and optimized, equipped with back-axis system, the main spindle and sub-axis can be synchronously rotated for machining, i.e., it solves the processing of the back side of the parts, and further improves the machining efficiency. CNC Walking Centring Machine can automatically complete a number of composite machining processes such as external turning, frontal drilling, frontal tapping, frontal boring, thread turning, slotting, cross drilling, milling square, milling slot, radial tapping, cutting off, back turning, back drilling, back boring, back tapping and other complex machining processes on the axle parts made of carbon steel, stainless steel, and copper.
CNC centring machine in turning processing, chip forming is difficult to deal with things; for the turning tool to find a suitable chipbreaker slot is not so easy to complete the task. Milling cutters for mill-turn applications produce short chips, which significantly improves chip control. In turning, the eccentric quality of workpieces such as crank journals, eccentric cams, etc. can lead to unbalanced forces, which can have a negative effect on machining, while mill-turn machining avoids such negative effects due to the low rotational speed of the workpieces. CNC centring machine in the manufacture of the introduction of milling and turning composite processing not only to solve the processing problems but also significantly improve the yield. The adoption of a relatively new machining method, with the availability of suitable modern machine tools and the correct choice of cutting tools, will provide a significant increase in productivity. The centring machine can achieve complete machining of the workpiece in a single clamping. After the parts cut off by the subspindle can grab the parts and complete the parts cut off surface of the back of the drilling, boring, milling and other processes.
CNC centring machine processing materials to adapt to a wide range of cold-drawn or polished bar, square drawn light profiles, triangular or shaped profiles, PVC and other types of smooth profiles. Compound type centring machine - equipped with side processing function system, in addition to the processing of the above types and material range, but also to adapt to the side of the composite processing. Such as milling polyhedra, milling grooves, milling mesh diagonal grooves, milling curved surfaces, drilling holes on the side and rigid tapping, lettering and many other composite machining processes.
